Introduction

In injection molding, the cooling system is one of the most critical yet often underestimated factors affecting product quality and production cost. Cooling typically consumes up to 70% of the molding cycle time. An inefficient design can lead to longer cycles, higher energy costs, and quality issues like warpage, sink marks, and uneven shrinkage.

At Rheologist Gaze & Solutions, we utilize Moldex3D Cooling Simulation to help mold designers and manufacturers achieve efficient cooling performance, uniform temperature control, and shorter cycle times—all before the mold is even built.

Why Mold Cooling Design Matters

The cooling system’s purpose is to remove heat from the molten plastic efficiently and uniformly. Poorly designed cooling channels can cause:

• Uneven part shrinkage

• Increased cycle time

• Surface blemishes or dimensional instability

• Frequent mold rework

As product geometries grow more complex, relying solely on experience or empirical design methods is no longer enough. Simulation-based cooling design using Moldex3D offers a precise and predictive way to address these issues.

How Moldex3D Cooling Simulation Works

Moldex3D provides a 3D, physics-based analysis of heat transfer, coolant flow, and temperature distribution across both the mold and the plastic part.

Key capabilities include:

1. Conventional and Conformal Cooling Evaluation
   Simulate straight-drilled or conformal channels (ideal for additive-manufactured molds) and compare their thermal efficiency.

2. Cooling Performance Visualization
   Get 3D temperature maps to identify hot spots, cold zones, and heat accumulation areas.

3. Design Parameter Optimization
   Adjust channel layout, diameter, flow rate, and coolant type to balance cooling efficiency and manufacturability.

4. Integration with Filling and Warpage Simulation
   Combine cooling simulation with filling and packing analyses to predict final part deformation with high accuracy.

5. DOE and Automatic Optimization
   Moldex3D’s DOE tool systematically explores multiple design variables and process settings to deliver the best combination of cooling performance and cycle time.

Benefits of Using Moldex3D Cooling Simulation

Case Example: Automotive Component Cooling Optimization

An automotive housing component was facing warpage and long cooling time issues. Using Moldex3D Cooling Analysis, our engineering team at Rheologist Gaze & Solutions redesigned the cooling layout and applied conformal channels to improve heat extraction efficiency.

Results achieved:

• 30% reduction in cycle time

• Improved part dimensional stability

• Uniform temperature across cavities

• Reduced residual stress and warpage

This simulation-driven redesign led to faster production, fewer mold trials, and a more reliable manufacturing process.

Why Partner with Rheologist Gaze & Solutions

As an authorized reseller and certified service partner of Moldex3D, Rheologist Gaze & Solutions provides not only simulation software but also expert consultancy in:

• Plastic product and mold design

• Moldex3D simulation setup and analysis

• DOE-driven cooling system optimization

• Fixture and tool design integration

We combine engineering expertise, simulation intelligence, and hands-on industry experience to help manufacturers achieve:

• Lower operational costs

• Consistent product quality

• Sustainable and energy-efficient manufacturing

Conclusion

Efficient cooling system design is the foundation of high-performance injection molding. With Moldex3D Cooling Simulation, engineers can visualize heat transfer behavior, optimize cooling efficiency, and ensure uniform part quality—before cutting any steel.

At Rheologist Gaze & Solutions, we empower industries to innovate, create, and excel using the power of simulation-driven cooling design.
